Set Top Box Amlogic S905X3 Support 8K
- Model No.: Set Top Box Amlogic S905X3 Support 8K
- CPU: Amlogic S905X3 64-bit quad core ARM® Cortex™ A55 CPU
- GPU: G31™ MP2 GPU processor
- ROM: DDR3: 2GB/4GB
- eMMC: 32GB(Option: 16GB/64GB)
- OS: Android 9.0
- WiFi: IEEE 802.11 a/b/g/n/ac; 2.4G/5G
- Bluetooth: BT; Support Voice Remote
Set Top Box Amlogic S905X3 Support 8K
|
Specifications |
|
|
Model No. |
Set Top Box Amlogic S905X3 Support 8K |
|
CPU |
Amlogic S905X3 64-bit quad core ARM® Cortex™ A55 CPU |
|
GPU |
G31™ MP2 GPU processor |
|
ROM |
DDR3: 2GB/4GB |
|
eMMC |
32GB(Option: 16GB/64GB) |
|
OS |
Android 9.0 |
|
WiFi |
IEEE 802.11 a/b/g/n/ac; 2.4G / 5G |
|
Bluetooth |
BT; Support Voice Remote |
|
Video&Audio CODEC |
|
|
Video |
Ÿ Amlogic Video Engine (AVE) with dedicated hardware decoders and encoders Ÿ Support multi-video decoder up to 4x1080P@60fps Ÿ Supports multiple "secured" video decoding sessions and simultaneous decoding and encoding Ÿ Video/Picture Decoding - VP9 Profile-2 up to 8Kx4K@24 fps - H.265 HEVC MP-10@L5.1 up to 8Kx4K@24 fps - AVS2-P2 Profile up to 8Kx4K@24 fps - H.264 AVC HP@L5.1 up to 4Kx2K@30fps - MPEG-4 ASP@L5 up to 1080P@60fps (ISO-14496) - WMV/VC-1 SP/MP/AP up to 1080P@60fps - AVS-P16(AVS+) /AVS-P2 JiZhun Profile up to 1080P@60fps - MPEG-2 MP/HL up to 1080P@60fps (ISO-13818) - MPEG-1 MP/HL up to 1080P@60fps (ISO-11172) - RealVideo 8/9/10 up to 1080P@60fps - Multiple language and multiple format sub-title video support - MJPEG and JPEG unlimited pixel resolution decoding (ISO/IEC-10918) - Supports JPEG thumbnail, scaling, rotation and transition effects - Supports *.mkv,*.wmv,*.mpg, *.mpeg, *.dat, *.avi, *.mov, *.iso, *.mp4, *.rm and *.jpg file formats |
|
Audio |
Supports MP3, AAC, WMA, RM, FLAC, Ogg and programmable with 7.1/5.1 down-mixing Low-power VAD Built-in serial digital audio SPDIF/IEC958 input/output and PCM input/output 3 built-in TDM/PCM/I2S ports with TDM/PCM mode up to 384kHz x 32bits x 16ch or 96kHz x 32bits x 32ch and I2S mode up to 384kHz x 32bits x 16ch Digital microphone PDM input with programmable CIC, LPF & HPF, support up to 8 DMICs Built-in stereo audio DAC Supports concurrent dual audio stereo channel output with combination of analog+PCM or I2S+PCM |
|
I/O |
|
|
1*HDMI |
HDMI 2.1,Support HDMI CEC, Dynamic HDR and 8Kx4K@24 max resolution output |
|
1*AV OUT |
480i/576i standard definition output |
|
3*USB |
1*USB 3.0 2*USB 2.0 |
|
1*IR Reciver |
Remote Reciver Connect |
|
1*RJ45 |
Ethernet Interface Support 10/100/1000M |
|
1*TF CARD |
Support 4GB/8GB/16GB/32GB/64GB |
|
Power |
DC 5V/2A |
|
Others |
|
|
Image |
HD JPEG, BMP, GIF, PNG, TIF |
|
Language |
English French German Spanish Italian etc multilateral languages |
|
Option |
Browse all video websites, support Netflix, Hulu, Flixster, Youtube, etc. Apps download freely form android market, amazon app store etc. Local Media playback, Support HDD, U Disc, TF Card. |
Elevate Your Viewing Experience with the Set Top Box Amlogic S905X3 Support 8K
The Set Top Box Amlogic S905X3 Support 8K redefines home entertainment with its cutting-edge features and performance. Here's why it stands out:
-
Powerful Performance: Equipped with the Amlogic S905X3 chipset, our set-top box delivers lightning-fast processing speed and smooth performance, ensuring seamless streaming and multitasking.
-
8K Resolution Support: Experience breathtaking clarity and detail with support for 8K resolution, bringing your favorite movies, shows, and games to life like never before.
-
HDR and Dolby Vision: Enjoy vivid colors, deep contrasts, and stunning visuals with HDR and Dolby Vision support, enhancing your viewing experience with lifelike imagery and immersive audio.
-
Enhanced Connectivity: Connect effortlessly to your home network and other devices with built-in Wi-Fi, Ethernet, HDMI, and USB ports, ensuring versatile connectivity options for seamless integration with your existing setup.
-
Smart Features: Access a world of entertainment with pre-installed apps, streaming services, and games, offering endless entertainment possibilities at your fingertips.
-
User-Friendly Interface: Navigate through menus, apps, and settings with ease using our intuitive user interface, designed for simplicity and convenience.
-
Compact and Stylish Design: With its sleek and compact design, our set-top box complements any home entertainment system, adding style and functionality to your living space.
-
Regular Updates: Stay up-to-date with the latest features, performance improvements, and security patches through regular firmware updates, ensuring your set-top box remains optimized and secure.
Experience the future of home entertainment with the Set Top Box Amlogic S905X3 Support 8K. Transform your TV into a cinematic experience and enjoy unparalleled viewing quality and performance.
